STARTING AND OPERATING 357
Whenever the Rear View Camera image is activated
through the "Backup Camera" button in the "Controls"
menu, and the vehicle speed is greater than, or equal to
8
mph (13 km/h), a display timer for the image is initiated.
The
image will continue to be displayed until the display
timer exceeds 10 seconds.
NOTE:
• If the vehicle speed remains below 8 mp
h (13 km/h), the
Rear View Camera image will be displayed continuously
until deactivated via the touchscreen button "X", the trans
-
mission is shifted into PARK, or the ignition is cycled to
the
OFF position.
• The touchscreen button "X" to disable display of the
cam
era image is made available ONLY when the vehicle is
not in REVERSE.
When enabled, active guide lines are overlaid on the image
to i
llustrate the width of the vehicle and its projected backup
path based on the steering wheel position. A dashed center
line overlay indicates the center of the vehicle to assist with
parking or aligning to a hitch/receiver.
When enabled, fixed guide lines are overlaid on the image to
illu
strate the width of the vehicle.
Different colored zones indicate the distance to the rear of
the
vehicle.
The following table shows the approximate distances for
each
zone:
Trailer Hitch Zoom
If equipped, the Trailer Hitch Zoom feature aids the driver in
lini
ng up a trailer to the vehicle’s trailer hitch by allowing the
driver to toggle back and forth between the normal view and
a 4X zoom mode. The image is displayed on the radio screen
when the transmission is shifted into REVERSE, as well as
manually in certain situations through the controls screen.
Zone Distance To The Rear Of The Vehicle
Red 0 - 1 ft (0 - 30 cm)
Yellow 1 ft - 6.5 ft (30 cm - 2 m)
Green 6.5 ft or greater (2 m or greater)
5
