398 IN CASE OF EMERGENCY
LED Front Fog Lamp
If your vehicle is equipped with LED fog lamps they are
repla
ced as an assembly.
Rear Tail, Stop, Turn Signal, And Backup Lamp
1. Re
move the two screws that pass through the bed sheet
meta
l.
Tail Lamp Screws
2. Pull the outboard side of the lamp rearward, far enough
to u
nsnap the two receptacles on the outboard side of the
lamp housing, from the two plastic snap post retainers in
the outer box side panel.
3. Remove the screws from assembly bracket to access the
thre
e bulb sockets.
Assembly Bracket
CAUTION!
Do not touch the new bulb with your fingers. Oil
contam
ination will severely shorten bulb life. If the bulb
comes in contact with any oily surface, clean the bulb
with rubbing alcohol.
