F30 – – Spare
F31 – 10 Amp Red DIAGNOSTIC PORT
F32 – 10 Amp Red
Heating Ventilation Air Conditioning Mod
(
HVA
C CTRL MOD)/Steering Column Lock
(SCL)/Occupant Classification Module (OCM)/
Driver Presence Detection Module (DPDM)
F33 – 10 Amp Red
ParkTronics System (PTS)/Infrared Camera
M
odu
le (IRCM)/Airbag Disable Lamps
(AIRBAG DISABLE LMPS)
F34 – 10 Amp Red
Electronic Stability Control (ESC)/Electric
Hydra
ulic Power Steering (EHPS)/Smart Bar
Control Module (SBCM) WAKE UP
F35 30 Amp Pink – BRAKE VAC PMP - If Equipped
F36 30 Amp Pink – TRAILER TOW MOD - If Equipped
F37 30 Amp Pink – TRAILER TOW CONN 7W - If Equipped
F38 20 Amp Blue – Engine Control Module ECM
F39 – – Spare
F40 – 15 Amp Blue
Drivetrain Control Module (DTCM)/Axle Lock
(
AXL
E LOC) FT_RR
Cavity
Cartridge Fuse
Micro Fuse Description
