452 SERVICING AND MAINTENANCE
4. Disengage the two retaining tabs that secure the air filter
access door to the HVAC housing.
Air Filter Retaining Tabs
5. Remove the air filter from the HVAC air inlet housing.
Pull
the filter elements out pinching them to the right for
clearance.
Air Filter
6. Install the A/C air filter with the air filter position indica-
tors
pointing in the same direction as removal.
CAUTION!
The cabin air filter is identified with an arrow to indicate
airfl
ow direction through the filter. Failure to properly
install the filter will result in the need to replace it more
often.
