SERVICING AND MAINTENANCE 455
Wiper Blade Removal/Installation
1. Lift the wiper arm to raise the wiper blade off of the glass,
unti
l the wiper arm is in the full up position.
Wiper Blade With Release Tab In Locked Position
2. T
o disengage the wiper blade from the wiper arm, press
the
release tab on the wiper blade, and while holding the
wiper arm with one hand, slide the wiper blade down
towards the base of the wiper arm.
Wiper Blade With Release Tab In Unlocked Position
3. With the wiper blade disengaged, remove the wiper
blad
e from the wiper arm.
4. Gently lower the wiper arm onto the glass.
CAUT
ION!
Do not allow the wiper arm to spring back against the
glass
without the wiper blade in place or the glass may
be damaged.
1 — Wiper Blade
2 — Wiper Arm
3 —Release Tab
1 — Wiper Blade
2 — Wiper Arm J Hook
3 — J Hook Retainer
