24-10515-13 Rev. – B-1
Appendix
B
This document contains confidential and proprietary information of Johnson Controls, Inc.
© 2010 Johnson Controls, Inc.
RECORDING QUALITY A
Use the table below to determine recording quality settings. The frame rate controls the
sampling rate of grabbing frames within a second, while the bit rate controls the quality of
individual images within a video frame.
NOTE
Currently, only the Nice protocol version 9.0 supports bit rate.
NOTE
The default bit rate for the Loronix protocol is 960 kbit/sec. For proper operation,
recording quality defined in this table should be registered in Loronix's recording
configuration.
Table B-1: Recording Quality
Quality in
P2000
Resolution Frame Rate Bit Rate (kbit/sec)
1 360x243 1 256
2 640x480 1 256
3 720x486 1 256
4 360x243 1 512
5 640x480 1 512
6 720x486 1 512
7 360x243 1 768
8 640x480 1 768
9 720x486 1 768
10 360x243 2 256
11 640x480 2 256
12 720x486 2 256
13 360x243 2 512
