Johnson Controls P2000 User Manual

Operation DVR Integration Option
3-14 24-10515-13 Rev. –
This document contains confidential and proprietary information of Johnson Controls, Inc.
© 2010 Johnson Controls, Inc.
Video Display Aspect Ratio
You can choose the video player to retain or not retain aspect ratio in the recording
displayed. Keeping the aspect ratio prevents distortion of the image.
Viewing area with Keep Aspect Ratio
selected.
Viewing area with Keep Aspect Ratio
un-selected. Notice the image distortion.
 To adjust the aspect ratio:
1. Go to Vi
ew>Keep Aspect Ratio.
2. To keep the aspect ratio, select this option (a check mark will be
displayed).
To display recording without keeping the aspect ratio, un-select this option
(no check mark will be displayed).
Video Player
The video viewing area is an ActiveX based video player that can render
heterogeneous video streams (H.263+ or MPEG-4 etc.) or various video files.
AV Player Functions
Play – Click to play the recording.
Play speed – Click to play the recording with altered speed. From the drop-down
list select 1/2 to play the recording at half speed, or 2 to play the recording at
double speed (available for some vendors only).
Stop – Click to stop playing the recording.
Pause – Click to pause playing the recording.
