Johnson Controls P2000 User Manual

Configuration DVR Integration Option
2-8 24-10515-13 Rev. –
This document contains confidential and proprietary information of Johnson Controls, Inc.
© 2010 Johnson Controls, Inc.
 Escalation
 MSEA
For reference use the section “Alarm Options Field Definitions” on
page 2-26.
Click OK to save your changes and return to the Alarm Categories window.
9. Repeat steps 6 - 8 to configure all Alarm Categories assigned to this AV
switch.
10. Click OK to save your changes and close the Edit AV Switch window.
11. Click Done to close the CCTV/AV Configuration window.
NOTE
For any DVR configuration changes to take effect, the CCTV Server must
be stopped and restarted using P2000 Service Control. This should be
done at the completion of your configuration session.
When a new AV Switch is created, a corresponding icon is displayed under the root
AV Switches icon in the CCTV/AV Configuration window. The icons for all AV
Switch components are listed under it.
Edit AV Switch Field Definitions
The Edit AV Switch window opens at with the General tab active. You must enter
information in all Edit AV Switch tabs to complete your configuration of the AV
Switch.
If you enable a function that is not available for the particular protocol, then the
operator’s action will have no effect. The system does not check whether the
functions selected at the AV Switch are compatible with the functionality of the
equipment.
