Johnson Controls P2000 User Manual

Configuration DVR Integration Option
2-2 24-10515-13 Rev. –
This document contains confidential and proprietary information of Johnson Controls, Inc.
© 2010 Johnson Controls, Inc.
After items have been added, you can edit them as desired.
The CCTV/AV Configuration
window is accessed from the P2000 Main menu.
 T
o access the CCTV/AV Configuration window:
1. From the P2000 Main menu, select Options>CCTV/A
V>Configuration.
2. If prompted, enter the password
(Johnson Controls uses master as the
default setting). The CCTV/AV Configuration window opens.
 T
o add an item to the CCTV/AV Configuration window:
1. From the configuration tree, click the root
icon for the item you wish to add.
2. To access configuration windows, either click the Add button at the bottom
of th
e window or right-click to access a shortcut button and select Add. The
appropriate window appears.
3. Add the information according to the field definitions and click OK to return
to the CCTV/AV Configuration window. When windows offer several
configuration tabs, such as in the Edit AV Switch window, configure each tab
in turn, as applicable. You may not be able to access some tabs until a
minimum of information has been entered into the active tab.
4. When all settings have been entered, click OK to sav
e your settings and
return to the CCTV/AV Configuration window. Verify that the settings for the
new item are listed in the right side of the window.
5. Continue to add items in this manner unt
il all items and their related controls
have been configured.
 T
o edit CCTV/AV configuration items:
1. From the configuration tree, right-click the item to
be configured and select
Edit (you can also select the item and click Edit from the shortcut button).
The Edit window appears.
2. Complete your changes and click OK
to save the settings.
3. Verify that the changes appear in the right side of the CCTV/AV
Configuration window
.
NOTE
Any changes will take effect only after the CCTV Server has been stopped
and restarted using Service Control. For instructions see “Starting and
Stopping Service Control” in the P2000 Software User Manual.
