Johnson Controls P2000 User Manual

DVR Integration Option Configuration
24-10515-13 Rev. – 2-13
This document contains confidential and proprietary information of Johnson Controls, Inc.
© 2010 Johnson Controls, Inc.
NOTE
Mode settings only apply to alarms that are generated for input points
mapped to cameras in the input to Camera application. “Camera Send
Alarm” event actions will ignore the Mode option selected here.
Timezone – From the drop-down list select the time zone during which messages that
pass the Message Filter Group criteria will be transmitted to a mapped camera as
P2000 alarms. Select <Always Enabled> if you wish to send messages at all times.
Message Filter Group – From the
drop-down list select the Message Filter Group that
defines which of the messages that pass the Timezone criteria will be transmitted to
a mapped camera as P2000 alarms. Select <None> if you wish to transmit all
messages.
System Alarm Options Tab
Select Alarm Categories
Edit
– Click this button to open the Alarm Options window and edit the alarm
options for a highlighted Alarm Category. See “Alarm Options Field Definitions” on
page 2-26 for more information.
Add – Click this
button to open the Add Alarm Categories window and assign this
alarm to an additional Alarm Category.
Delete –
Click this button to delete a highlighted Alarm Category from the list of
categories assigned to this alarm.
