Namespace Definitions DVR Integration Option
A-6 24-10515-13 Rev. –
This document contains confidential and proprietary information of Johnson Controls, Inc.
© 2010 Johnson Controls, Inc.
Access Rights
Ch#.Partition Integer CR Managing partitions. Not supported in current
release.
Ch#.Public Integer CR Define public accessibility. Value: 1 for Yes.
Ch#.ClientLockId 32 char WR Can be used by a client to lock access to this
camera
General Commands/Status
Ch#.GeneralString VarChar CWR A string of characters that is written to the
specific camera to annotation of all that is
being recorded or monitored from it.
Ch#.ChannelStatus Integer WRU Bit flagged field to define the equipment
status. The status flags are to be defined at a
later stage.
The status field is only to be used for those
status identifications that are NOT part of the
original item list.
Ch#.StartRecordExists Integer CR Only present if a recording configuration
exits. Default value: 1.
Ch#.StartRecord Integer RW Issue start recording. Only present if a
configuration database exists.
Ch#.StopRecordExists Integer CR Only present if a configuration database
exists.
Ch#.StopRecord Integer RW Stop recording on the channel. Only present
if a configuration database exists.
Ch#.RewindExists Integer CR Only present if a configuration database
exists.
Ch#.Rewind Integer RW Rewind playback video. Only present if a
configuration database exists.
Ch#.PauseExists Integer CR Only present if a configuration database
exists.
Ch#.Pause Integer RW Pause playback video. Only present if a
configuration database exists.
Ch#.FastForwardExists Integer CR Only present if a configuration database
exists.
Ch#.FastForward Integer RW Only present if a configuration database
exists.
Ch#.StartPlaybackExists Integer CR Only present if a configuration database
exists.
Tag Name Type Flags Description
