iSTAR Edge G2 Controller Installation and Configuration Guide 15
Chapter 1 - Overview
Compliance
• FCC, CE, EN50133, UL294, UL1076, UL2610, UL60950 by CB Scheme (International Safety) & RoHS.
Environmental Requirements
Table 3 on Page 15 shows the iSTAR Edge G2 environmental requirements.
Table 3:Environmental Requirements
Status Range
Operation 32° F (0° C) to 120° F (48.9° C)
Storage 4° F (-20° C) to 158° F (70° C)
Enclosure Dimensions and Weight
Table 4 on Page 15 shows the iSTAR Edge G2 enclosure/can dimensions and weight.
Table 4:Enclosure Dimensions and Weight
Width
12 inches (30.48 x 30.48 cm)
Height
12 inches (30.48 x 30.48 cm)
Depth
4.5 inches (11.4 cm)
Upper Mounting Holes
9 inches (22.86 cm) centre to centre
Bottom Mounting Holes
10.5 inches (26.67 cm) below the upper mount holes.
Weight
<10lbs (<4.6 kg)
iSTAR Edge G2 Layout
The iSTAR Edge G2 board layout is displayed in Table 5 on Page 16.
