iSTAR Edge G2 Controller Installation and Configuration Guide 37
Chapter 5 - Controls and Displays
Table 13:LED Operation
Indicator Input power
good, door closed
Input power
good, door open
Input power lost,
backing up/sleeping
Input
power <
8V
Controlled
by
Power LED On On n/a Off Hardware
Bright White LED On Off Off n/a Firmware
Relay Activation LEDs On On Off Off Firmware
All other indicators, and LCD backlight Off On Off n/a Firmware
All other indicators, and LCD backlight
if configured OFF in host
Off Off Off n/a Firmware
You can configure the LCD backlight and LEDs, except the Power LED, to remain off regardless of tamper state through the
host. The LCD display and associated diagnostic tests are not UL-evaluated.
Table 14 displays the function and designation of each LED.
Table 14:LED functions
LED Function Comment
DS22 Main Power - Internal View Always on if Voltage in > 8V
DS21 Main Power - External View Super bright White LED, visible from outside of
the enclosure when the door is closed. Off
when the door is open.
Relay Outputs
DS17 Output 1 NO Closed Always on if Voltage in > 8V
DS18 Output 2 NO Closed Always on if Voltage in > 8V
DS19 Output 3 NO Closed Always on if Voltage in > 8V
DS20 Output 4 NO Closed Always on if Voltage in > 8V
Serial
DS8 RS-485-1 Tx Off when door is closed
DS7 RS-485-1 Rx Off when door is closed
DS11 RS-485-2 Tx Off when door is closed
DS10 RS-485-2 Rx Off when door is closed
DS14 RS-485-3 Tx Off when door is closed
DS13 RS-485-3 Rx Off when door is closed
DS25 RS-485-4 Tx Power LEDs for each RS-485
DS24 RS-485-4 Rx Power LEDs for each RS-485
