iSTAR Edge G2 Controller Installation and Configuration Guide 75
Chapter 9 - Diagnostics
iSTAR Controller
Cluster
Information on devices within the cluster.
iSTAR Databases
iSTAR database contents. See iSTAR Databases on Page 75 for more
information.
High Assurance
(FICAM)
Information on High-Assurance database contents.
Level Control
General Controlled I/O
Communication Server
Event Manager
Time Server
Access Control
Connected Devices
Console
Reader and I/O
Last Input Change
Last Output Change
Last Card Swipe
Last Card Swipe for Reader
Logs
Click the download icon to download the iSTAR log.
Level Control
You can enable the various fields listed in the Level Control section of Table 23 to be written to the serial/console log within
the Level Control menu for the iSTAR controller.
NOTE
Contact Software House Technical Support before enabling level control options.
Reader and I/O
The Reader & I/O section displays information about devices, such as readers, that communicate with iSTAR Edge G2. The
Reader and I/O section also displays diagnostic output for iSTAR readers and cards.
You can perform reader and input/output diagnostics from the Reader and I/O menu by checking the Enable checkbox and
then clicking the save icon to display information from the fields listed in the Reader and I/O section of Table 23
NOTE
Enabling Reader and I/O diagnostics degrades iSTAR controller performance. Disable this when not in use.
iSTAR Databases
In the database table, you can click the following database names to display more details about the selected database:
• Personnel – Displays personnel records.
