Jonker Sailplanes JS3 RES User Manual

JS-MD 3 RES Maintenance Manual
Supplement
MD11-AMM-00-002
Issue: 00
Rev. 00
Rev. Date: 23-May-22
Page 6-9
Right battery connector
The right battery connector is located in the rear fuselage compartment and is the connector
interface for the right high voltage battery.
Figure 6-8 Right battery connector wiring
NOTE: The debug adapter and bootloader switch is optional.
CAUTION: The 10k ohm resistor has to be included for the system to work with both HV
batteries. The 10k resistor is used to identify the connected battery.
Wire number
Destination
Wire
number
Destination
PSEN_GND
BMS Bootloader
(Optional)
CAN_L
Refer to 6.17
P_SEN
BMS Bootloader
(Optional), 118
CAN_H
Refer to 6.17
RXD
Debug adapter
137
Left Battery Connector
TXD
Debug adapter
140
Right Battery Connector
SHIELD
Debug adapter
135
Charger Connector
36
GND
004
Motor controller
20
GND
007
Motor controller
119
RFU
