JS-MD 3 RES Maintenance Manual
Supplement
MD11-AMM-00-002
Issue: 00
Rev. 00
Rev. Date: 23-May-22
Page 4-12
No
Description
No
Description
1
EMRAX 208 Electrical motor
2
Locking wire
3
Propeller bolt
4
Pylon cover
5
Propeller ring
6
Pylon
7
Propeller
8
Pylon nut
9
Pylon driver bush
10
Washer
11
Pylon driver bolt
12
Pylon base bracket bolt
13
Pylon base bracket
14
Pylon Sleeve nut
15
Pylon base bush
16
Pylon sleeve
17
Pylon Sleeve bolt
Figure 4-6 Pylon assembly
Maintenance & Checks
Before any run-up of the system be sure to check the pylon for any cracks, chips, or
any visible signs of stress or delamination.
The pylon can be cleaned of any bugs and dirt after every flight using a damp cloth.
If the pylon has any visible damage ensure that is inspected and repaired by a qualified
maintenance organisation, to prevent further damage or failure.
Removal
1. Extend the pylon to a position slightly below the extended position to ensure the main
doors are fully open.
2. Switch off the RES master switch.
3. Disconnect the motor wires (HV, resolver, and ground wires). Refer to the
