JS-MD 3 RES Maintenance Manual
Supplement
MD11-AMM-00-002
Issue: 00
Rev. 00
Rev. Date: 23-May-22
Page 8-6
Propulsion
When rotating the command button clockwise propulsion power is increased.
Figure 8-6 Propulsion screen
Battery voltages (12 V / HV)
RPM
Power delivered by batteries
State of Charge of HV batteries
Maximum cell temperature in HV
battery
Motor temperature
Controller temperature
The desired power can be adjusted in the propulsion mode as follows:
Clockwise rotation increase power
Anti-clockwise rotation decrease power
When the power is set to 0 kW, the Extended Mode is entered and the propeller aligned
vertically.
The pylon retraction mode is activated when the EXT/RETR switch is pushed downwards.
