Figure 4-2 Actuator assembly
4.2.1.2 Specification
Table 4-2 Actuator specifications
Parameter
Value
Part Number
107 09 230 00
Input voltage
12V
Maximum current
11.6A
4.2.1.3 Removal
1. Extend the pylon to a position slightly below the extended position.
2. Switch off the RES master switch.
3. Remove the main doors.
4. Support the pylon slightly below the extended position.
5. Remove Bell crank bolt (6).
6. Remove the Actuator front (11) from the actuator by unscrewing it.
7. Disconnect the actuator wiring.
8. Loosen the six Wheelbox cover plate bolts (10).
9. The actuator Sub assembly (12) can now be removed from the fuselage through the
wheelbox. The hole inside the wheelbox is big enough for the actuator to pass through.
10. The Actuator (5) can be removed from the Wheelbox actuator cover plate (8) by
loosening the two Actuator bracket bolts (1).
4.2.1.4 Installation
1. Fasten the Actuator (5) to the Wheelbox actuator cover plate (8) by fastening the
two Actuator bracket bolts (1).
2. Install the actuator Sub assembly (12) into the aircraft by inserting it through the hole
in the wheelbox.
3. Fasten the six Wheelbox cover plate bolts (10).
4. Connect the actuator wiring.
5. Fasten the Actuator front (11) to the actuator.
6. Install and fasten the Bell crank bolt (6).
