JS-MD 3 RES Maintenance Manual

Supplement

MD11-AMM-00-002

Issue: 00

Rev. 00

Rev. Date: 23-May-22

Page 4-13

4. Electrical motor section.

NOTE: It is advisable to remove the motor as it makes the handling of the pylon easier.

5. Disconnect the pylon driver arm by loosening the Pylon driver bolt (11)

6. Detach the Pylon (6) by loosening the four Pylon base bracket bolts (12)

NOTE: Be careful not to drop or damage the pylon when removing the bolts.

7. Remove the Pylon base brackets (13)

8. Remove the Pylon (6) from the fuselage.

NOTE: Be careful not to damage the various motor wires when removing the pylon.

9. The four Pylon base bushes (15) can now be removed.

10. The Pylon sleeve (16) can be removed by loosening the Pylon Sleeve bolt (17) and

nut (14).

Installation

1. Route the various motor wires through the pylon (refer to the
