JS-MD 3 RES Maintenance Manual
Supplement
MD11-AMM-00-002
Issue: 00
Rev. 00
Rev. Date: 23-May-22
Page D-2
Precharge Timeout!
Service Disconnect?
Voltage on high voltage rail does not reach battery voltage in
time. Main relay cannot be closed.
MC: BAD PARAMETER
Damaged Parameter
MC: POWER FAULT
Overall message of hardware monitoring 1
MC: RFE FAULT
Safety circuit faulty (only active with RUN)
MC: BUS TIMEOUT
CAN-Bus timeout
MC: FEEDBACK
Resolver signal faulty or missing
MC: POWER VOLTAGE
Power voltage missing
MC: MOTOR TEMP
Reduce Power Instantly!
Motor temperature too high (> 115 °C)
MC: DEVICE TEMP
Power Reduced
Device temperature too high (> 80°C)
MC: OVERVOLTAGE
Overvoltage (power voltage)
MC: I_PEAK
Overcurrent or strongly oscillating current detected
MC: RACEAWAY
Drive races (without command value, wrong direction)
MC: MOTOR TEMP 2
Motor temperature too high (second sensor) not used
MC: I Sensor
Current measurement error
MC: BALLAST
Ballast circuit overloaded
BATTERY A: Modul Timeout
Discharge Only Maintenance!
Error during selftest. Discharge only. Maintenance necessary.
BATTERY A: Cell Connection
Discharge Only Maintenance!
Error during selftest. Discharge only. Maintenance necessary.
BATTERY A: Temperature Reg.
Discharge Only Maintenance!
Error during selftest. Discharge only. Maintenance necessary.
BATTERY A: Cell Voltage Reg.
Discharge Only Maintenance!
Error during selftest. Discharge only. Maintenance necessary.
BATTERY A: No Module Data
Discharge Only Maintenance!
Error during selftest. Discharge only. Maintenance necessary.
BATTERY A: Battery TOO HOT
Reduce Power !!!
Battery > 70°C.
BATTERY A:
Battery Empty !!!
SOC < 3%
