Installation
1. Make sure the Resolver plate (7) is fitted to the Emrax 208 HV (1) motor and in the
correct orientation. The Alignment marks (11) must lign up.
WARNING: The Resolver plate (7) has a specific orientation to the Motor. If this orientation
is changed, the calibration of the resolvers will be out. The resolvers must be
recalibrated (refer to the Calibration & setup section). When the calibration is
out, the motor could behave unpredictably and start rotating even if no power
is requested by the DCU.
2. Fasten five out of the six Motor fastening bolts (8). Do not fasten the motor fastening
bolt indicated in Figure 4-8 yet.
3. Fasten the motor ground wire using the remaining Motor fastening bolt (8).
4. Fasten the three high voltage wires to the corresponding High voltage terminals (6).
Be sure to match the colour markers on the wires and the terminals.
WARNING: If the colours are not in the correct sequence, the motor will not turn in the
correct direction or could cause damage to the system.
5. Connect the motor Resolver wires (9).
6. Install the Pylon rear cover (4) by fastening the six Pylon cover fastening bolts (5).
