JS-MD 3 RES Maintenance Manual
Supplement
MD11-AMM-00-002
Issue: 00
Rev. 00
Rev. Date: 23-May-22
Page 4-29
4.7.1.1 Removal
1. Extend the pylon to a position slightly below the extended position to ensure the main
doors are fully open.
2. Switch off the RES master switch.
NOTE: The main doors could be removed first to improve the ease of access.
3. Loosen the two Front door hinge bolts (3) to free a front door from the corresponding
main door.
4.7.1.2 Installation
1. Fasten a front door to the main door by fastenings the two Front door hinge bolts (3).
CAUTION: The order of washers and the other components should match the overview
figure.
2. Ensure that one end of the Front door spring (7) is hooked behind the Front door top
hinge as indicated in the overview figure.
