JR ProPo XG8 User Manual

10
Concerningtheconnectionandincorporationof
theservosandthepowersource
ReceiverConnection
Preparation
Sincethereceiverissusceptibletovibration,shock,andwater,
anti-vibrationandwaterproofingmeasuresshouldbesecurely
implemented.
•
Iftheconnectorsbecomedetachedwhileflying,therewillbea
riskofuncontrolledoperation.Pleasesecurelyinsertallofthe
connectorsasfarastheywillgo.
•
Inthesituationwhererelayconnectors(extensionleads)are
usedduringtheinstallationrubberspongeshouldbewrapped
roundtheconnectorstofixthem.
Beabsolutelysurenottoleavetheconnectorshanging
unsupported.
•
InJRreceivers,thechannelsforconnectingservosaregivennamesratherthannumbers.
Fromthispointonwardinthemanualthereceiverchannelsaredescribedusingtheirnames,sobecarefulofthiswhenreadingthemanual.
Concerningthe2.4GHzBandCharacteristicsandReceivingRadioWave
Weak
Signal
Strong
Reception
Strong
Reception
Theantennapart(30mm)shouldbeinstalled
perfectlystraight.Ifbent,stablereceivingwill
notbepossible.
MaterialFrame
Receiving
Sensitivity
(Low)
Receiving
Sensitivity
(High)
ReceivingSensitivity(High)
ReceivingSensitivity(High)
RX
RX
RX
RX
RX
RX
× WrongAntennaInstallation
Thearrowsshowthereceivingdirectionwith
regardtotheantenna.
RGCable150
RG831BMainUnit
RemoteAntenna
Built-inAnten
▼ FrontFace
▲ RearFace
Strong
Reception
Strong
Reception
Weak
Signal
RA01TSideView
DONOTbendtheantennatip!
Built-inAntenna
CircuitBoardFace
Duetothe2.4GHzbandwhichhasastrongdirectionalityin
itsradiowaves,thereceivingsensitivitywillgreatlydiffer
dependingonthedirectionagainsttheantenna.Sincethe
antennareceivesradiowavesfromthesidesratherthan
fromthetip,pleasetakeadequatecareoftheantenna
directionwheninstallingtheantennainthemodel.
Inthecasewheretherearetwocoaxialantennasinthereceiver
mainunit,thefacesofeachantennashouldbeinstalledsothat
theyareatrightanglestoeachother,ratherthanbeingparallel.
Notethatinordertoallowcertainandstablecommunicationsto
becarriedout,itisrecommendedthateachantennashouldbe
installedwithaseparationof30mmormore.
Ifeachantennaisinstalledinparallel,the
receivingefficiencywillbereduced.
Thebuilt-inantennaoftheremoteantennais
installedonthesurfaceofthecircuitboard.
Carewillberequiredinthesituationwherethe
built-inantennahasbeeninstalledbesidea
shieldingmaterial,sincethereceiving
sensitivitywillbeconsiderablydegraded.
*Theremoteantennareceivesthedataandalso
feedsbacktothetransmitter.
Theantennapartshouldbeinstalled
inaperfectlystraightcondition.
Coaxialpartoftheantennacan
bebenthowever,donotbendit
inarightangle.Thiswilldamage
theinternalantennawires.
Inthesituationwheretheantennahasbeen
attacheddirectlytoashieldingmaterialsuch
ascarbonormetal,thereceivingsensitivity
oftheinstalledantennasurfacewillbe
considerablyreduced.Whentheantennais
tobeinstalledonthiskindofshielding
material,eitherseparatetheantennaasfar
aspossiblefromthematerial,orinthecase
wheretheradiowaveshieldingmaterialis
theaircraftbodyitselfprojecttheantenna
outsidetheaircraftbody.
*Takecarenotto
damagethe
antennas
projectingfromthe
aircraftbody.
Aircraftbodysurfacemadefrom
shieldingmaterial.
*Whenusingagyro,carryoutthe
connectionaccordingtothegyro
operationmanual.
ReceiverBattery
BINDPLUG
RudderChannel
GyroSensitivity
AdjustingChannel
AuxiliaryChannel
AuxiliaryChannel
BindingPlug
Sensor
Y-Harness
Switch
Harness
AuxiliaryChannel
ElevatorServo
AileronServo
ThrottleServo
SENSOR
Inserttheconnector,
takingadequate
careofthe
direction.
Thisisusedwhen
settingthebinding
Forconnectingthe
sensor,connectthe
Y-Harness(sold
separately)tothe
[BIND/BATT/SENS]
terminal.
