ELEVATOR→CAMBERMIXING
EachFunctionintheFunctionList
FunctionExplanation
Thisfunctionappliesmixingtothemainwingcamber(wingtype)fromtheelevator
operation.Adjustmentofthewingrootflapsandwingtipflaperonsseparatelyintheup
anddowndirectionsispossible.
ThisfunctioncanbesetforeachFlightMode.
•
SettingMethod
Adjustmentofthedirectionandamountwithregardtotheflapsandflaperonsfromthe
elevatoroperationispossible.Rotatethedialtoselecteachitem,thenpressthedialto
displaythesettingscreenandsettheamountanddirection.NotethatthecurrentFlight
Modeisdisplayedatthetopleftofthescreen.Additionallybyutilizingtheoffset,the
referencepointwherethemixingstartscanbemoved.
•
【ELEV→CAMB】
Theso-calledaircombatflaps(snapflaps)canbeusedinaircraftwithmain
wingsthathave3-servo(channel)structures.Torealizestability,reducingthe
mixingamountofthewingtipaileronsratherthanthewingrootflapswill
causeaneffectthatreduceswingtwistingandachievesstability.
•
Hint
Glider
Themixingreference
pointfromthe
elevatoroperationcan
beoffset.
FlapLinkedMovement
Amount
AileronLinked
MovementAmount
CurrentFlightMode
