JR ProPo XG8 User Manual

74
TELEMETRY
EachFunctionintheSystemList
FunctionExplanation
•
Thisfunctioncarriesoutsettingsrelatingtotelemetry,whichallowsconfirmationofavarietyofinformationfromthe
aircraftusingthetransmitter.Inadditiontothescreennumericalvalues,becausealarmsareincorporatedthatcanbe
settodesiredvalues,theaircraftconditionscanbeconfirmedwithouttakingyoureyesofftheaircraft.(However,itwill
benecessarytoconnectvarioussensorstothereceiver.)
SettingMethod
Itispossibletoselecteachofthescreenitemsandsetthem.Eachalarmcanbedemonstratedbyclickingon
themark.
SelecteachitemtomovetotheSettingscreens.
ThisscreenistheSettingscreen.TheTelemetryInformationdisplayscreencanbedisplayedfromthe
InitialINFOscreenbyrotatingthedialtotheright.(Seeexplanationonnextpage.)
•
● InitialScreen
● Receiver
Battery
●
Temperature
● Rotation
Speed
● Altimeter
●
Variometer
● ForMotive
Power
Battery
【TELEMETRY】
BatteryVoltage
fortheReceiver
Temperature
RotationSpeed
Altitude
Becausethesesensorsarenotmeasuringinstruments,no
warrantyismadefortheaccuracyofthemeasurementresults.
ItispossibletoswitchON/OFFthealarmsoundusingtheselectedswitch.
Helicopter
Airplane
Glider
Thissetsthevoltagewherethealarmwillsound.
Atthesametime,theTelemetryscreenwillflash.(3.0V-9.0V)
Thisselectstheunits.(°C,°F)
Voltageatwhichthealarmsounds(0.1V-655.3V)
BatteryNominalCapacityValue(0mAh-30000mAh)
RemainingAmountAlarm:Analarmwillsoundwhentheinput
batterynominalcapacityremainderfallsbelowthesetrate.
Caution
Thisselectsthegearratio(ifagearboxisused)
Threetypesofalarmsoundsareincorporated.
↑:Whenthealtitudebecomesgreaterthanthesetvalue.
↓:Whenthealtitudebecomeslessthanthesetvalue.
〜:Whenflyingwithinthesetaltituderange.
OnPage1,settingsduringascendingcanbemade,andon
Page2settingsduringdescendingcanbemade.
Units(m/sec.orfeet/sec.)
ItispossibletoswitchON/OFFthealarmsoundusingtheselectedswitch.
Settingispossibleoftheascendingrateatwhichthealarmsoundson
Page1,andofthedescendingrateatwhichthealarmsoundsonPage2.
m/sec.:Thisshowstheascendinganddescendingrateofthealtitude.
Units(MetersorFeet)
Thealtitudesatwhichthealarmwillsoundcanbeset.Alarmaltitude(1-2000m)
ThisistheDelayTimeoftheMeasurementDisplayin
theMaximumHoldValueDisplayScreen(0.5-10.0secs)
MeasurementPauseafterSwitchingtheFlightMode
Thisisthetimebetweentheinterruptionofthedatafrom
thereceiverandthesoundingofthealarm.
Thissetsthetemperaturewherethealarmwillsound.(30-500°C)
ThisistheNumberofBlades(1-5)
Variometer
MotivePowerBattery(Voltage/Capacity)
