SWASHMIXING
EachFunctionintheFunctionList
FunctionExplanation
Thisfunctionsetsthemixingrelatingtoswashplateswiththe1-4servounitsthatcontrolthemovementof
themainrotor.Thisswashmixingisforeasilycarryingoutswashplatemovementsettingforhelicopters
thatincorporateCCPMsystems.
CCPMisatypeofpitchmixinginwhichtheservosaredirectlylinkedtotheswashplatesothatthepitchis
mechanicallyoperated.Inthistransmitter,6typesofswashplatescanbeselected.
Matchingtheaircraftʼs swash plate specification, settheswashtype setting using “SWASH TYPE” in the
SystemList.AnE-ringfunctionisalsoincorporatedthateasilyadjuststheswashmaximumangle.
•
SettingMethod
Thesettingitemsonthescreenwillbedifferentaccordingtothenumberofservos.Thisshowsasetting
examplewiththreeservossetat120degrees.
•
Thesettingvalueinthisfunctionshouldbebetween0and125.(TheE-ringis150.)
ThesettingvaluescanberesetusingtheCLRkey.
Actuallyoperatetheservosandcarefullyconfirmthesettingsbeforeflying.
•
•
● Page1Screen
CautionItem
● Page2Screen
Hints
【SWASHMIX】
● Page4Screen
● Page3Screen
Thecontrolsurfaceangleofeachchannel
servocanbeadjusted.
Althoughthestandardvalueis60%,this
shouldbere-adjustedaccordingtotheswash
mechanism.EXPhasaneffectofreducingthe
errorbyapproximatingthehornʼscircular
movementtoastraight-linemovement.
Thiscorrectsthetiltoftheaileronsideand
elevatorsidewhenthepitchhasbeenmoved
upanddown.Adjustmentofthemixing
amountfromthepitchtotheaileronsand
elevatorscanbecarriedoutseparatelytothe
frontandrearandtotheleftandright.The
switchingON/OFFofthemixingonthis
screencanbesetusingtheswitches.
Thisisusedforcorrectioninthesituation
wheretheaileronandelevatoroperations
mutuallyinfluenceeachother.Theaileron
andelevatormutualmixingamountcan
beseparatelyadjusted.Theswitching
ON/OFFofthemixingonthisscreencan
besetusingtheswitches.
Thisisaconvenientfunctionthat
automaticallycorrectstheswash
electronicallybythesameangleinall
directions.Theoperationofthestickcan
beconfirmedonthegraph.Thediameter
ofthecircleistheswashtiltangle,which
canbeset.
Helicopter
Inordertousethisfunction,thisitem
mustbesettoACT.
ServoOperationEXPOSetting
EachServoMovementAmount
ThisistheE-ring.The
diameter(angle)canbe
increasedordecreased
usingthesettingnumerical
valuetotheleft.
