CAMBERSYSTEM
EachFunctionintheFunctionList
FunctionExplanation
Inthesituationofaircraftwhichhavefullaileronorflap+aileronmainwingswith
full-spanmoveablecontrolsurfaces,thesecontrolsurfacescanbemovedupanddown
simultaneouslytochangethewingtype.Becausechangingthewingtypecanvarythe
rateofdescentandthedrag,itwillbepossibletochangetheflightenduranceandthe
glidingratio.ThesesettingscanbesetforeachFlightMode.Inaddition,becausethe
delaytimeduringtheswitchingcanalsobeadjusted,theaircraftwillnotreactwildly.
Duringthisdelaytime,rapidcancellationwillalsobepossibleusingtheelevatorstick.
•
SettingMethod
Althoughtheyarenotshownonthescreen,theaileronandflapcamberadjustmentsin
eachFlightModeshouldbecarriedoutusingtheFlapTrim[FLAP/RTRM]andFlaperon
Trim[FPRN/LTRM]locatedbelowthetransmitterLED.EachoftheseTrimscanbeoperated
upanddownsimultaneouslyforeachcontrolsurface.Next,settheDelayTimeandBrake
functionwhentheFlightModehasbeenchangedonthescreen.Rotatethedialtoselect
thesettingitem,thenpressthedialtodisplaytheadjustingboxandthenmakethe
settings.
•
【CAMBERSYS.】
IftheCamberPosition(TrimPosition)thathasbeensetineachoftheFlight
Modesistobepreventedfromoperatingmistakenly,themethodofsetting
thisTrimtotheoperationinvalidsituationcanbeusedtoavoidoperation.
AftersettingthenumberofstepsoftheFLAPandFPRMTrimintheTrim
SystemscreenintheSystemList,theseshouldbesettozero.Bydoingso,
eventhoughtheTrimleverwillnotactuallyoperate,thesettingpositionswill
remainmemorized.
•
Hint
●Page1
●Page2
Glider
FlightModeName
DelayTimeSetting
BrakeFunctionUsage
PermitorDeny
・ThissetstherangeoftheBrakemovementusingtheElevatorStick.
Becausethedelayoperationwillbediscontinuedevenifthestick
exceedsthenumericalvaluesonlymomentarily,itwillbepossibleto
respondtosuddencircumstances.
