11
IfthiskeyispressedwhentheINFOscreenisbeingdisplayed,thescreenwillchangeto
theMyListscreen.Thiscanbeusedformovingtoeachoftheotherfunctions.
Althoughthiskeybasicallyinitializesthepresetvalue,itoperatesasdisplayedwhenan
itemotherthananarrowisdisplayedonthescreen.
Though this key has no allocated function, it operates as displayed when an item is
displayedonthescreen
Ex.:Timerstart/stopkeyetc.
Also,whenthiskeyispressedatthetimeofenteringnumberswithadial,thenumber
changesattentimesthenormalspeed.
Inadditiontothestandardbuttonkeysforinput,thistransmitteremploysadial.Atthetimeofsetting,
almostalloperationscanbedonebythedialintuitively.Basicoperationforthedialisrotatingtotheright
orleft,andpressing(click).
・A“click”soundisheardforconfirmedinputwhentheinputisvalid.
・A“click”soundmaybeheardwithoutcausinganychangeinnumericalnumbersonthedisplay.Thisis
becausenumericalnumbersbelowthedecimalpointarenotdisplayedwhilethesetvalueisactually
changedinternally.
・Astothebuttonkeysontheleftsideofthetransmitter,theyoperateasdisplayedwhenatriangular
arrowisdisplayedontheLCD.Whenthenameofthekey(abbreviated)isdisplayedontheLCD,thekey
willfunctionasdisplayed.
Thekeydisplayinthismanualisasshowninthefigurebelow.
NamesandFunctionsoftheInputKeys
Preparation
Dial
Turn right/left to select an item and to increase/decrease the preset
value.
Further,press(click)thedialtodecideontheselecteditemandtoexit
thesettingstate.
DialDisplay
ENTERKey
LISTKey
CLEARKey
FUNCTIONKey
CLEARKey
ENTERKey
LISTKey
Infunctionfixing,whenthiskeyispressedthescreenchangestotheFunctionListingscreen.
FUNCTIONKey
