JR ProPo XG8 - Battery Installation and Charging Procedures; Transmitter Battery Charging Method

8
Beforechargingthebattery,becertaintoreadtheprecautionswrittenonthebatterysurfacesticker.
ThetransmitteroperatesexclusivelywithgenuineJRLi-febatteries.Donotusethetransmitterwithotherrecharge-
ablebatteriesorwithdrycellbatteries.
Duringcharging,thetransmittershouldbeswitchedoff.WhenthetransmitterisintheONcondition,chargingwill
nottakeplace.
Ontheotherhand,ifthecordisinsertedintheTrainerJackintheconditionwherethepowerswitchisintheOFF
condition,itwillbepossibletoenjoyusingthetransmitterasaflightsimulatorusingtheACadaptorelectricpower.
Sincethebuilt-inbatterywillnotbeused,thiswillallowenjoymentwhileconservingenergy.
MethodsofMountingandRemovingBatteries
Whilepressingthetrianglemarkontherearsurfacebatterylid,slidethelidinthearroweddirectionandremovethebatterycover.
I nserttherechargeablebatteryconnectorintothetransmitterbatteryconnector.
Inserttherechargeablebatteryintothebatterybox,andmountthebatterycover,takingcarenottopinchtheleadwires.
InserttheACadaptorintotheACelectricpowersocket.
ConnecttheplugoftheACadaptorasfarasitwillgointotheDCpowerjackofthetransmitter.
During charging, the transmitter LED will light in a reddish purple color. When charging has been
completed,theLEDwillswitchoff.
Thestandardchargingtimeisapproximately3hours.
Afterthecharginghasbeencompleted,quicklydetachalloftheconnections.
Absolutelydonotleavethebatteryconnectedasitistothepowersource.
InthesituationwherethetransmitterLEDdoesnotlight,anerrorwillhaveoccurred.
Inthissituation,detachtheACadapterplugonce,thenre-insertit.
InthecasewheretheLEDdoesnotlightevenafterthecablehasbeeninsertedandremovedseveraltimes,please
contactthiscompanyʼsServiceSection.
* Be certain to use the genuine JR XG8 dedicated AC adapter (NEC-A912).
NormalchargingcannotbecarriedoutusingotherACadapters.Further,do
notusethisACadapterforchargingotherproducts.
DonotusetheACadaptercordwhilethecordis
stillbundledtogether,sincetherewillbeariskof
heatgeneration.
MethodofChargingtheTransmitterBattery
Preparation
TotheACElectricPowerOutle
TotheRechargingPowerSourceJack
(Exclusivelyfortransmitterswith
built-inLi-ferechargeablebatteries)
When removing the connector, press
theleverparttoreleasethelockwhile
pullingouttheconnector.
Caution
Caution
※※※※ ※※※※ ※※※※ ※※※※ ※※※※
BatteryConnector
BatteryBox
BatteryCover
Powersourcejack
forrecharging(DC9V)
1
2
3
1
2
3
4
※
9V12WACAdaptorfor
Recharging(NEC-A912)
*Caution:Thisisnota
batterycharger.
