JRC JMA-2353 User Manual

Chapter 4 MAINTENANCE
4.6 TROUBLE SHOOTING
4-26
7ZXRD0013 : Scanner NKE-2063 (6kW)
Name/Type Parts No. Code Shape (mm) Quantity Location Application
Fuse
ST4-6.3AN1
F2 5ZFCA00051
4 * Not used for this display unit
Fuse
ST4-3.15AN1
F2 5ZFCA00047 4 * Not used for this display unit
Fuse
ST4-5AN1
F3 5ZFCA00050 4 * Not used for this display unit
Carbon brush
54531-01
– BRXP05247 2 Scanner
For the scanner
motor
7ZXRD0031 : Display unit NCD-2237
Name/Type Parts No. Code Shape (mm) Quantity Location Application
Fuse
ULTSC3.15AN1
F1-1 5ZFCA00033 2
processing
unit
Display Unit
(For DC24V)
Fuse
ULTSC6.3AN1
F1-2 5ZFCA00034 3
processing
unit
Display Unit
(For DC12V)
Fuse
ULTSC10AN1
F2 5ZFCA00035 2
processing
unit
For
NKE-2043/
NKE-2063
Connector
LTWBD-06FFA-ll7001
P3 5JCDX00032 1
processing
unit
Mainly for GPS
connection
Connector
LTWBD-08FFA-ll7001
P4 5JCDX00034 1
processing
unit
Mainly for
connecting course
equipment such as
a GPS compass
44.0
18.0
44.0
18.0
20
Φ5.2
20
Φ5.2
20
Φ5.2
31.8
Φ6.35
31.8
Φ6.35
31.8
Φ6.35
32.0
Φ8.0
