Chapter 7 SPECIFICATIONS
7.3 DISPLAY UNIT
7-8
7.3.2 OPERATION PANEL
(1) Structure Integrated on the display unit
(2) Controls GAIN
SEA
RAIN
MULTI
(3) Keys
Cursor keys
STBY Stops transmission (Turns off the equipment if
simultaneously pressed with "TX/PRF")
TX/PRF Starts transmission (Turns off the equipment if
simultaneously pressed with "STBY")
Changes PRF during transmission.
RANGE+ Increases the distance range.
RANGE- Decreases the distance range.
USER Registers in the user menu
BRILL Adjusts CRT brightness
ENT Enter key (Selects menu items, etc)
CLEAR Cancels operations
MENU Opens/closes the menu screen
7.3.3 AIS FUNCTION
(1) Screen
Number of targets Up to 50 targets (stores up to 500 ship static data)
Target information Select MMSI, call sign, ship name, COG, SOG,
CPA, TCPA, direction, distance, latitude, longitude
and/or status, etc. as you need to display.
Filters Distance only
Active targets Not available
Dangerous ship targets No CPA/TCPA decision
(2) Operation Built-in (Options not required)
