Chapter 1 GENERAL AND EQUIPMENT COMPOSITION
1.3 CONFIGURATION
1-3
INSTRUCTION MANUAL
1
1.3 CONFIGURATION
Radar Configuration and Ship's Mains
RADAR MODEL Scanner Display Unit SHIP'S MAINS
JMA-2353 NKE-2043
JMA-2354 NKE-2063
NCD-2237 12/24 VDC
Scanners and Transmitted Output Powers
SCANNER TYPE
TRANSMITTED
OUTPUT
POWER
BAND
RATE OF
ROTATION
JMA-2353 620mm Radome 4kW
JMA-2354 3.9 FT SLOT ANTENNA 6kW
X 27 rpm
Reference:
1 An optional rectifier NBD-865 is necessary for using Ship's Mains 100-200/200-240 VAC,
50/60Hz, 1.
2 If connecting to gyro with synchro signal output or step signal output, optional NSK unit
NCT-4106A is required.
Supplied accessories
PRODUCT NAME/MODEL QUANTITY JRC CODE REMARKS
Instruction manual
7ZPRD0846
1 7ZPRD0846 This manual
Installation manual
7ZPRD0848
1 7ZPRD0848
Quick manual
7ZPRD0850
1 7ZPRD0850
Read me 1 7ZPRD0853
Power cord
H-CFQ-6776
1 CFQ-6776 2m
Radar equipment cable
H-CFQ5761-15
1 CFQ5761-15
Supplied with the scanner unit
NKE-2043
Radar equipment cable
H-CFQ5746-20
1 CFQ5746-20
Supplied with the scanner unit
NKE-2063
Food
MTV303344
1 MTV303344
To Next Page
