Chapter 2 OPERATIONS
2.7 SOFT KEY OPERATION
2-65
2
INSTRUCTION MANUAL
Soft key 3: Mark Display Mark DISP Off
"Mark Display": The marks and lines are displayed.
"Mark DISP Off": The marks and lines are hidden.
Soft key 4: Track Display Track DISP Off
"Track Display": The own track is displayed.
"Track DISP Off": The own track is hidden.
2.7.16 SETTING MOB
MOB is the mark of a person or an object overboard. If someone or something falls
overboard, set MOB to memorize the latitude/longitude of the location and display the
mark. Also, a straight line from the own ship to the mark is displayed.
Reference:
Bearing signal input and latitude/longitude data input are required to display MOB.
This function is initially set to off. To use this function, set this to on by referring to "■
Soft Key Menu Setting" in "4.10 Control" of the Installation Manual.
1 Select MOB on the soft key menu.
The "MOB" soft key display appears.
2 Operate with the soft keys.
Soft key 1: MOB Setting
Sets the MOB at the own ship's position.
Soft key 2: MOB Release
The displayed MOB is cleared.
Soft key 3: Not available
Soft key 4: Not available
"MOB" is colo
