Chapter 2 OPERATIONS
2.7 SOFT KEY OPERATION
2-44
2.7.7 DISPLAYING THE RADAR ALARM AND AUTOMATIC
ACQUISITION OPERATIONS
With a fan-shaped range made, the radar alarm can give an alarm to ships that enter or
depart from the range.
Reference:
"Alarm2" is initially set to off. To use this function, set this to on by referring to "■ Soft Key
Menu Setting" in "4.10 Control" of the Installation Manual.
1 Select Alarm1 Alarm2 on the soft key menu.
The soft key menu disappears and "Make Zone" of the soft key display is
color-inverted.
"Alarm1" is activated.
The soft key menu disappears and "Make Zone" of the soft key display is
color-inverted.
"Alarm2" is activated.
"Alarm1" is colo
