Chapter 2 OPERATIONS
2.7 SOFT KEY OPERATION
2-45
2
INSTRUCTION MANUAL
2 Operate with the soft keys.
Soft key 1: When Alarm1 is selected
Off On
When Alarm2 is selected
Off On
Turns on/off the alarm display.
Soft key 2: When Alarm1 is selected
Sector Rectangle AZ1
When Alarm2 is selected
Sector Rectangle AZ2
"Sector":
Displays a fan-shaped radar alarm.
"Rectangle":
Displays a rectangle-shaped radar alarm.
"AZ1" "AZ2":
Displays the acquisition area.
Soft key 3: When Alarm1 is selected
In Out
When Alarm2 is selected
In Out
Sets the alarm issuing conditions for the radar alarm.
"In": An alarm is issued when ship enters.
"Out": An alarm is issued when ship departs.
Soft key 4: When Alarm1 is selected
Make Zone
When Alarm2 is selected
Make Zone
"Make Zone" "Make Zone":
When "Make Zone" of the soft key menu is selected, "Target
Select" of the soft key display is color-inverted.
Reference:
When "Alarm1"/"Alarm2" is not selected on the soft key menu, press the soft key 4 to
activate the Alarm1/Alarm2 function.
