Chapter 7 SPECIFICATIONS
7.1 GENERAL SPECIFICATIONS
7-1
7
INSTRUCTION MANUAL
Chapter 7 SPECIFICATIONS
7.1 GENERAL SPECIFICATIONS
(1) Class of Emission P0N
(2) Display Raster Scan, PPI
(3) Screen 10.4-inch Monochrome LCD, VGA (640 480 dots)
(4) Range Scale 0.125, 0.25, 0.5, 0.75, 1.5, 3, 6, 12, 24, 48, 72 NM
(6 kw for 72 NM )
User can add 1, 2, 4, 8, 16 or 32NM.
* Off Center is not available at maximum range.
(5) Range Resolution Less than 30m
(6) Minimum Detective Range Less than 40m
(7) Range Accuracy Less than 1% of the maximum distance of the range scale
in use or less than 15m whichever is larger
(8) Bearing Accuracy Less than 1°
(9) Bearing Indication Head-up, North-up, Course-up
(10) Ambient Condition
Standards IEC60945 Ed.4.0
Temperature
Scanner Operation: -25 to +55°C / Storage: -25 to +70°C
Other Unit except Scanner
Operation: -15 to +55°C
Relative Humidity
Entire Unit +40°C, 93%
Vibration
Entire Unit 2 to 13.2 Hz, amplitude±1mm
13.2 to 100 Hz 0.7 G
Velocity of the wind 51.5m/s (100kn)
(11) Power Supply Input DC+24V (Cable length of 30m or less)
DC+12V (Cable length of 20m or less)
(12) Power Consumption In calm wind:
Approx. 60W (4kW)
Approx. 85W (6kW)
Maximum (Velocity of the wind: 100kn):
Approx. 60W (4kW)
Approx. 180W (6kW)
(13) Pre-heating Time Approx. Within 1min30sec
