3ņ39
[IV] Parallel Cursor Bearing Fix Mode (Bearing Mode)
If this function is set to ANGLE , the parallel cursor also rotates in accordance with the bearing while
the own ship is turning. If the function is set to SCREEN FIX , the parallel cursors are fixed within
the radar display even while the own ship is turning. The parallel cursors are displayed at the same
place even while the own ship is turning.
Procedure 1 Press [RADAR MENU] key.
Press [3] key.
Press [5] key.
Press [2] key.
The Parallel Cursor Menu will appear.
2 Press [4] key.
The Bearing Mode Setting Menu will appear.
Angle Fix : The angle of the parallel cursors
is set in true bearing.
For NUP and CUP, the cursors
are displayed in true bearing
irrespective of changes in the
course of own ship.
For HUP, the angle of the parallel cursors changes as the course of own
ship changes.
Screen Fix : Parallel cursors are fixed on the radar screen.
For HUP, NUP, and CUP, the angle of the parallel cursors stays the same
on the screen.
When own ship is engaged in TM motions, the parallel cursors move as
own ship moves.
Heading Fix : The parallel cursors are displayed while the relative angle of the ship's
heading bearing line stays the same.
For HUP, the ship's heading bearing line does not change even though the
course of own ship changes; therefore, the parallel cursors do not move.
For NUP, the ship's heading bearing line changes as the course of own
ship changes; therefore, the parallel cursors also change as the course of
own ship changes.
To Next Page
