5 Inserting a vertex into a line (Insert)
Procedure 1 Press [5] key while the Edit User MAP
Menu is open.
The navigation information insertion mode will
be activated.
Insert will appear in the CURSOR mode
field at software button Õ² located at the top
right corner of the radar display described in
Section 2.3.3.
2 Use the trackball to move the pointer to
the line that is to become a vertex, and
press [ENT] key.
The cross cursor mark will appear on the
selected point.
3 Use the trackball to move the cross
cursor mark to a new point where a
vertex is to be formed, and press [ENT] key.
A vertex will be inserted into the selected line.
4 To insert another vertex, repeat steps 2 and 3.
5 Press [0] key when finishing the insertion of all vertices.
The CURSOR mode at the upper right of the radar display will change to the general
operation mode, terminating the navigation information insertion mode.
(Example)
