Juniper EX2200 Complete Hardware Guide

Aviso Leia as instruções de instalação antes de ligar o sistema à sua fonte
de energia.
¡Atención! Ver las instrucciones de instalación antes de conectar el sistema
a la red de alimentación.
Varning! Läs installationsanvisningarna innan du kopplar systemet till dess
strömförsörjningsenhet.
Related
Documentation
General Safety Guidelines and Warnings for EX Series Switches on page 113•
• Laser and LED Safety Guidelines and Warnings for EX Series Switches on page 121
• Grounded Equipment Warning for EX Series Switches on page 134
• Connecting AC Power to an EX2200 Switch on page 73
• Connecting AC Power to an EX3200 Switch
• Connecting AC Power to an EX4200 Switch
• Connecting AC Power to an EX4500 Switch
• Connecting AC Power to an EX8200 Switch
• Connecting DC Power to an EX3200 Switch
• Connecting DC Power to an EX4200 Switch
• Connecting DC Power to an EX4500 Switch
• Connecting DC Power to an EX8200 Switch
• Connecting AC Power to an XRE200 External Routing Engine
• Connecting DC Power to an XRE200 External Routing Engine
Chassis Lifting Guidelines for EX2200 Switches
The weight of a fully loaded EX2200 switch chassis is approximately 10 lb (4.5 kg).
Observe the following guidelines for lifting and moving an EX2200 switch:
•
Before installing the switch, read the guidelines in “Site Preparation Checklist for EX2200
Switches” on page 33 to verify that the intended site meets the specified power,
environmental, and clearance requirements.
•
Before lifting or moving the switch, disconnect all external cables.
Related
Documentation
General Safety Guidelines and Warnings for EX Series Switches on page 113•
• Installation Instructions Warning for EX Series Switches on page 127
• Mounting an EX2200 Switch on page 53
Copyright © 2010, Juniper Networks, Inc.128
Complete Hardware Guide for EX2200 Ethernet Switches

Juniper EX2200 Specifications

General

Throughput	77 Mpps
MAC address table	8000 entries
Jumbo frames support	Yes
Number of VLANs	1024
Networking standards	-
Switch type	Managed
SFP module slots quantity	4
Installed SFP modules quantity	0
Basic switching RJ-45 Ethernet ports quantity	48
Stackable	No
Product color	Black
Power consumption (typical)	100 W
Operating altitude	0 - 3048 m
Non-operating altitude	0 - 4877 m
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 45 °C
Storage relative humidity (H-H)	0 - 95 %
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Depth	254 mm
Width	441 mm
Height	43 mm
Weight	3600 g
