Page #26 background imageLoading...
Page #26 background image
Figure 1: Front Panel of an EX2200 Switch with 48 Gigabit Ethernet Ports
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
0 1 2
SYS
ALM
SPD
DX
EN
POE
3
46
47
Network
ports
Port status mode LEDs
Mode
button
SFP
uplink
ports
Chassis
status
LEDs
g027000
Figure 2: Front Panel of an EX2200 Switch with 24 Gigabit Ethernet Ports
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
0 1 2
SYS
ALM
SPD
DX
EN
POE
3
Network
ports
Chassis
status
LEDs
g027002
SFP
uplink
ports
Port status mode LEDs
Mode
button
Related
Documentation
Chassis Status LEDs in EX2200 Switches on page 11
Network Port and Uplink Port LEDs in EX2200 Switches on page 12
Network Port Connector Pinout Information for an EX2200 Switch on page 20
Rear Panel of an EX2200 Switch on page 6
Installing a Transceiver in an EX Series Switch on page 65
Removing a Transceiver from an EX Series Switch on page 95
Installing and Connecting an EX2200 Switch on page 51
Rear Panel of an EX2200 Switch
The rear panel of the EX2200 switch consists of the following components:
Management Ethernet port
USB port
Console port
Protective earthing terminal
ESD point
Air exhaust
Copyright © 2010, Juniper Networks, Inc.6
Complete Hardware Guide for EX2200 Ethernet Switches

Table of Contents

Other manuals for Juniper EX2200

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Juniper EX2200 and is the answer not in the manual?

Juniper EX2200 Specifications

General IconGeneral
Throughput77 Mpps
MAC address table8000 entries
Jumbo frames supportYes
Number of VLANs1024
Networking standards-
Switch typeManaged
SFP module slots quantity4
Installed SFP modules quantity0
Basic switching RJ-45 Ethernet ports quantity48
StackableNo
Product colorBlack
Power consumption (typical)100 W
Operating altitude0 - 3048 m
Non-operating altitude0 - 4877 m
Storage temperature (T-T)-40 - 70 °C
Operating temperature (T-T)0 - 45 °C
Storage relative humidity (H-H)0 - 95 %
Operating relative humidity (H-H)10 - 85 %
Weight and Dimensions IconWeight and Dimensions
Depth254 mm
Width441 mm
Height43 mm
Weight3600 g
