Juniper EX2200 Complete Hardware Guide

Table 3: CLI Equivalents of Terms Used in Documentation for EX2200 Switches
Additional
Information
Item in
DocumentationValue (CLI)Description (CLI)Hardware Item (CLI)
“Chassis Physical
Specifications for
EX2200 Switches” on
page 5
Switch chassis–One of the following:
•
EX2200-24T-4G
•
EX2200-24P-4G
•
EX2200-48T-4G
•
EX2200-48P-4G
Chassis
Understanding
Interface Naming
Conventions on EX
Series Switches
The switch does not
have actual FPCs. In
this case, FPC refers to
the switch itself.
Value of n is always 0.Abbreviated name of
the Flexible PIC
Concentrator (FPC)
One of the following:
•
EX2200-24T-4G
•
EX2200-24P-4G
•
EX2200-48T-4G
•
EX2200-48P-4G
FPC (n)
Understanding
Interface Naming
Conventions on EX
Series Switches
The switch does not
have actual PIC
devices; see entries for
PIC 0 through PIC 1 for
the equivalent item on
the switch.
n is a value in the range
of 0-1.
Abbreviated name of
the Physical Interface
Card (PIC)
PIC (n)
“Front Panel of an
EX2200 Switch” on
page 5
Built-in network ports
on the front panel of
the switch
PIC 0One of the following:
•
24x 10/100/1000
Base-T
•
48x 10/100/1000
Base-T
“Front Panel of an
EX2200 Switch” on
page 5
Built-in uplink ports on
the front panel of the
switch
PIC 14x GE SFP
“Optical Interface
Support in EX2200
Switches” on page 22
Optical transceiversn is a value equivalent
to the number of the
port in which the
transceiver is installed.
Abbreviated name of
the transceiver
Xcvr (n)
“Power Supply in
EX2200 Switches” on
page 14
AC power supplyValue of n is always 0.Built-in power supplyPower supply (n)
“Cooling System and
Airflow in an EX2200
Switch” on page 15
Fan tray–Fan trayFan tray
Copyright © 2010, Juniper Networks, Inc.8
Complete Hardware Guide for EX2200 Ethernet Switches

Juniper EX2200 Specifications

General

Throughput	77 Mpps
MAC address table	8000 entries
Jumbo frames support	Yes
Number of VLANs	1024
Networking standards	-
Switch type	Managed
SFP module slots quantity	4
Installed SFP modules quantity	0
Basic switching RJ-45 Ethernet ports quantity	48
Stackable	No
Product color	Black
Power consumption (typical)	100 W
Operating altitude	0 - 3048 m
Non-operating altitude	0 - 4877 m
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 45 °C
Storage relative humidity (H-H)	0 - 95 %
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Depth	254 mm
Width	441 mm
Height	43 mm
Weight	3600 g
