Juniper EX2200 Complete Hardware Guide

CHAPTER 9
Installing Switch Components
•
Installing a Transceiver in an EX Series Switch on page 65
Installing a Transceiver in an EX Series Switch
The transceivers for EX Series switches are hot-removable and hot-insertable
field-replaceable units (FRUs): You can remove and replace them without powering off
the switch or disrupting switch functions.
Use only optical transceivers and optical connectors purchased from Juniper Networks
for your EX Series switch.
NOTE: On an EX3200 switch, if you install a transceiver in a 1-gigabit uplink
module port, a corresponding network port from the last four built-in ports
is disabled. For example, if you install a transceiver in the 1-gigabit uplink
module port 2 (ge-0/1/3), then built-in port 23 (ge-0/0/23) is disabled. The
disabled port is not listed in the output of show interface commands.
Before you begin installing a transceiver in an EX Series switch, ensure that you have
taken the necessary precautions for safe handling of lasers (see “Laser and LED Safety
Guidelines and Warnings for EX Series Switches” on page 121).
Ensure that you have a rubber safety cap available to cover the transceiver.
Figure 24 on page 66 shows how to install an SFP transceiver. The procedure is the same
for all transceiver types.
To install a transceiver in an EX Series switch:
CAUTION: To avoid electrostatic discharge (ESD) damage to the transceiver,
do not touch the connector pins at the end of the transceiver.
1. Remove the transceiver from its bag.
2. Check to see whether the transceiver is covered by a rubber safety cap. If it is not,
cover the transceiver with a rubber safety cap.
65Copyright © 2010, Juniper Networks, Inc.

Juniper EX2200 Specifications

General

Throughput	77 Mpps
MAC address table	8000 entries
Jumbo frames support	Yes
Number of VLANs	1024
Networking standards	-
Switch type	Managed
SFP module slots quantity	4
Installed SFP modules quantity	0
Basic switching RJ-45 Ethernet ports quantity	48
Stackable	No
Product color	Black
Power consumption (typical)	100 W
Operating altitude	0 - 3048 m
Non-operating altitude	0 - 4877 m
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 45 °C
Storage relative humidity (H-H)	0 - 95 %
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Depth	254 mm
Width	441 mm
Height	43 mm
Weight	3600 g
