Connecting and Configuring an EX Series Switch (J-Web Procedure)
There are two ways to connect and configure an EX Series switch: one method is through
the console using the CLI and the other is using the J-Web interface. This topic describes
the J-Web procedure.
NOTE: Before you begin the configuration, enable a DHCP client on the
management PC you will connect to the switch so that the switch can obtain
an IP address dynamically.
NOTE: Read the following steps before you begin the configuration. You
must complete the initial configuration using EZSetupwithin 10 minutes. The
switch exits EZSetup after 10 minutes and reverts to the factory default
configuration, and the PC loses connectivity to the switch.
•
EX2200 switch—The LEDs on the network ports on the front panel blink
when the switch is in the initial setup mode.
•
EX3200, EX4200, EX4500, or EX8200 switch—The LCD displays a
count-down timer when the switch is in initial setup mode.
89Copyright © 2010, Juniper Networks, Inc.
Chapter 11: Performing Initial Configuration

Juniper EX2200 Specifications

General

Throughput	77 Mpps
MAC address table	8000 entries
Jumbo frames support	Yes
Number of VLANs	1024
Networking standards	-
Switch type	Managed
SFP module slots quantity	4
Installed SFP modules quantity	0
Basic switching RJ-45 Ethernet ports quantity	48
Stackable	No
Product color	Black
Power consumption (typical)	100 W
Operating altitude	0 - 3048 m
Non-operating altitude	0 - 4877 m
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 45 °C
Storage relative humidity (H-H)	0 - 95 %
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Depth	254 mm
Width	441 mm
Height	43 mm
Weight	3600 g
