Table 9 on page 15 lists the power consumed by each EX2200 switch model. The
maximum power available on a PoE port is 30 W for switches running Junos OS Release
10.3 or later and 15.4 W for switches running Junos OS Release 10.2 or earlier.
Table 9: Power Consumed by EX2200 Switches
Maximum PoE Power
Available
Maximum Power
Consumed by the Switch
Number of PoE-Enabled
PortsModel Number
–50 W–EX2200-24T
405 W60 W (when no PoE power is
drawn)
24EX2200-24P
–76 W–EX2200-48T
405 W91 W (when no PoE power is
drawn)
48EX2200-48P
Related
Documentation
AC Power Cord Specifications for EX2200 Switches on page 47•
• Rear Panel of an EX2200 Switch on page 6
• Power Specifications for EX2200 Switches on page 47
• Connecting AC Power to an EX2200 Switch on page 73
• Connecting Earth Ground to an EX Series Switch on page 67
Cooling System and Airflow in an EX2200 Switch
The cooling system in an EX2200 switch consists of two fans along the rear of the chassis
that provide side-to-rear chassis cooling. In switch models with network ports in which
PoE is available, there is an additional fan in the power supply.
Figure 8 on page 16 shows the airflow in an EX2200 switch with network ports in which
PoE is not available.
15Copyright © 2010, Juniper Networks, Inc.
Chapter 2: Component Descriptions

Juniper EX2200 Specifications

General

Throughput	77 Mpps
MAC address table	8000 entries
Jumbo frames support	Yes
Number of VLANs	1024
Networking standards	-
Switch type	Managed
SFP module slots quantity	4
Installed SFP modules quantity	0
Basic switching RJ-45 Ethernet ports quantity	48
Stackable	No
Product color	Black
Power consumption (typical)	100 W
Operating altitude	0 - 3048 m
Non-operating altitude	0 - 4877 m
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 45 °C
Storage relative humidity (H-H)	0 - 95 %
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Depth	254 mm
Width	441 mm
Height	43 mm
Weight	3600 g
