CHAPTER 10
Cable Specifications and Pinouts
•
RJ-45 Connector Pinouts for the SRX340 Services Gateway Ethernet Port on page 37
•
RJ-45 Connector Pinouts for the SRX340 Services Gateway Console Port on page 37
•
Mini-USB Connector Pinouts for the SRX340 Services Gateway Console Port on page 38
RJ-45 Connector Pinouts for the SRX340 Services Gateway Ethernet Port
Table 12 on page 37 describes the RJ-45 connector pinouts for the Ethernet port.
Table 12: RJ-45 Connector Pinouts for the SRX340 Services Gateway
Ethernet Port
SignalPin
BI_DA+1
BI_DA2
BI_DB+3
BI_DC+4
BI_DC5
BI_DB6
BI_DD+7
BI_DD8
Related
Documentation
RJ-45 Connector Pinouts for the SRX340 Services Gateway Console Port on page 37•
• Mini-USB Connector Pinouts for the SRX340 Services Gateway Console Port on page 38
RJ-45 Connector Pinouts for the SRX340 Services Gateway Console Port
Table 13 on page 38 describes the RJ-45 connector pinouts for the console port.
