K&R ACD320 Series User Manual

ACD320user manual Function parameters list
- 43-
5: Motor running reverse
6: Null speed operating
7: Upper limit frequency reached
8: Lower limit frequency reached
9～12: Reserved
13:High pressure arrives detect value
14:Low pressure arrives detect value
15:Sleep status indication
16:Lack of water alarm ingdication.
17:Non-zero speed operating.
18:Running
19:Reserved
20:Reserved
21:Simple PLC run for a cycle until output of
signal.
22:Reserved
23:Reserved
24:Reserved
F2.21
Relay TA/B/C
output selection 3 ○ 72
F2.22
AO1 Analog output
Selection
0: Setting frequency
1: Running frequency
2: Output current
3:Output voltage
4: Running speed
5: Outputpower
6: Output torque
7: AVI input value
8: ACI input value
9～10: Reserved
0 ○ 73
F2.23 AO1 Lower limit 0.0%～100.0% 0.0% ○ 74
F2.24
Lower limit
corresponding AO1
output
0.00V～100.0V 0.00V ○ 75
F2.25 AO1 Upper limit 0.0%～100.0% 100.0% ○ 76
F2.26
Upper limit
corresponding
AO1 output
0.00V～100.0V 10.00V ○ 77
F3 HumanMachine Interface Parameters
F3.00 User password 0～65535 0 ○ 78
F3.01
Application of
macroinstruction
0: General-purpose inverter
1233: The application macro of Offset printing
machine
1235: The application macro of engraving
machine
1237:Constant pressure water supply
macroinstruction
0 × 79
F3.02 Function selection
0：Jog running
0 ○ 80
