K&R ACD320 Series User Manual

ACD320user manual Function parameters list
- 44-
of M key
1.Switch between running forward and reverse
2: Elimate the set of UP/DOWN
F3.03
STOP function opt
ion
0:Keypad control valid
1: Keypad and terminal control valid
2: Keypad and communication control valid
3: All control modes valid
0 ○ 81
F3.04 Reserved 2 ○ 82
F3.05
operation status
display parameter
option
Displayed Message Code
1183 ○ 83
BIT0: Running frequency 1
BIT1: Setting frequency 2
BIT2: Output current 4
BIT3: Output voltage 8
BIT4: Running speed 16
BIT5: Output power 32
BIT6: Output torque 64
BIT7: DC bus voltage 128
BIT8: PID setpoint 256
BIT9: PID feedback 512
BIT10: Input terminal status 1024
BIT11: Output terminal status 2048
BIT12: AVI value 4096
BIT13: ACI value 8192
BIT14: Current segment of
multi-speed control
16384
BIT15: torque setting value 32768
Note: The set value is the sum of all displayed code, if the inverter need to display output current, running speed,
bus-bar voltage, set the value 4+16+128=148, the parameter can be displayed after saving and exiting the
set period.
F3.06
Stop status display
parameter option
BIT0：Setting frequency 1
207 ○ 84
BIT1：DC bus voltage 2
BIT2：Input terminal status 4
BIT3：Output terminal status 8
BIT4：PID setpoint 16
BIT5：PID feedback 32
BIT6：AVI value 64
BIT7：ACI value 128
BIT8：Current segment of
multi-speed control
256
F3.07
operation status
display preferential
option
0～15(0:invalid) 0 ○ 85
F3.08
IGBTmodule
temperature
0～100℃
Actual
value
* 86
F3.09 Software version 0.00～655.35
Actual
value
* 87
F3.10
Accumulative
operat ing time
0～65535h 0 * 88
