K&R ACD320 Series User Manual

ACD320user manual Function parameters list
- 46-
F4.04
The deceleration
time of JOG
running
0.1～3600.0s 10.0s ○ 101
F4.05 Skip frequency 0.00～F0.04 0.00Hz ○ 102
F4.06
Skip frequency
range
0.00～F0.04 0.00Hz ○ 103
F4.07
Traverse frequency
range
0.00～100.0%（relative to set frequency） 0.00% ○ 104
F4.08
Kick frequency
range
0.00 ～ 50.0% （ relative to traverse frequency
range）
0.00% ○ 105
F4.09
Traverse frequency
up time
0.1～3600.0s 5.0s ○ 106
F4.10
Traverse frequency
down time
0.1～3600.0s 5.0s ○ 107
F4.11
Fault auto-reset
times
0～3 0 ○ 108
F4.12
Interval time setting
of automatic
resetting fault
0.1～100.0s 1.0s ○ 109
F4.13
FDT level detection
value
0.00～F0.04 5.00Hz ○ 110
F4.14
FDT delay
detection value
0.00～100.0%（FDT level)） 5.0% ○ 111
F4.15
Frequency reaching
detection range
0.0～100.0%（maximum frequency） 0.0% ○ 112
F4.16
Energy
consumption(brake)
braking voltage
115.0～140.0%（standard DC bus voltage）380V 130.0%
○ 113
115.0～140.0%（standard DC bus voltage）220V 120.0%
F4.17 Speed display ratio
0.1～999.9%
Speed=120×runningfrequency×F4.17/pole number
100.0% ○ 114
F4.18
PID setpoint
Sources Option
0: Given by Keyboard(F4.19)
1: Given by Analog Channel AVI
2: Given by Analog Channel ACI
3: Given by Remote Communication
4: Multi-speed setpoint
0 × 115
F4.19 Preset PID setpoint 0.0%～100.0% 0.0% ○ 116
F4.20
PID Feedback
Sources Option
0: AVI Feedback
1: ACI Feedback
2: AVI+ACI Feedback
3: Communication feedback
4: AVI-ACI Feedback
0 × 117
F4.21
PID Output
Characteristics
Option
0: Positive
1: Negative
0 × 118
