124
LI - Input Parameters
Binary Speed Selection
Utilizes three binary-coded inputs for up to 7 speeds.
Older KEB elevator software and worldwide variants are available. Because of
this, several different truth tables for the Binary Speed selection are available:
Versions: LI03 Setting: NUM
US Lift 1.60, 1.62, 1.72 B(Level - Correction - Inspection) 0
US Lift 1.51, 1.61, 1.71 B(Inspection - Level - Correction) 1
Euro Lift 1.00, 2.20 B(Level - Correction - High) 2
- - LI16 Custom Input Decoding 3
The following are the corresponding logic tables. Although inputs I2...I4 are
shown, the inputs actually used for speed selection are congurable and
can be dened in LI04-11. Refer to Section 3.1.1 or 3.2.2 for input terminal
assignments.
Custom binary table selections can be created with LI16 Custom Input
Decoding.
LI03 = B(Level - Correction - Inspection), NUM = 0
US04
Binary Speed
Selection
Parameter
Control Inputs
I2 I3 I4
S
ZERO
- 0 0 0
S
LEVELING
LS01 1 0 0
S
HIGH
LS02 0 0 1
S
INSPECTION
LS03 1 1 0
S
CORRECTION
LS04 0 1 0
S
INTERMEDIATE 1
LS05 1 0 1
S
INTERMEDIATE 2
LS06 0 1 1
S
INTERMEDIATE 3
LS07 1 1 1
Symbol: 1 = Input is active
0 = Input is not active
