DG - Diagnostics Parameters (Combivis only)
The displayed numerical value is the sum of the individual output
weightings. For example, DG11 = 12 = Relay 1 (4) + Relay 2 (8).
Value: Description:
0 None
1 Output 1
2 Output 2
4 Relay 1
8 Relay 2
The displayed numerical value is the sum of the individual output condition
weightings.
Value: Description:
0 None
1 Condition 0
2 Condition 1
4 Condition 2
8 Condition 3
16 Condition 4
32 Condition 5
64 Condition 6
128 Condition 7
The Parameter Set indicates the state of the run sequence in the drive. This
diagnostic parameter only applies to control modes US04 Control Type =
Binary Speed Selection (1) and Digital Speed Selection (0).
Value: Description:
1 Pre-torque
2 Normal Acceleration
3 Normal Deceleration
4 One Floor Acceleration
5 One Floor Deceleration
6 Emergency Acceleration
7 Emergency Deceleration
This shows the calculated elevator speed in either FPM or m/sec
DG11
Output Status
DG16
Output Condition State
DG19
Parameter Set
DG50
Elevator Speed
parameter

KEB COMBIVERT F5 Specifications

General

Category	DC Drives
Enclosure Rating	IP20
Control Mode	Vector Control, V/f Control
Protection	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Short circuit
Fieldbus Communication	PROFIBUS, CANopen
Communication Interfaces	RS-485
Input Voltage	380-480V AC
Cooling Method	Forced air cooling (fan)
